Configuring LDP GR

Configuration
Prerequisites

Configuration Procedure

To do...
Enter system view
Enable LDP capability for a VPN
instance and enter MPLS LDP VPN
instance view
Configure the LSR ID for the VPN
instance
c
CAUTION:
For LDP-enabled interfaces, configurations in MPLS LDP VPN instance view
■
affect only interfaces bound to VPN instances, while configurations in MPLS
LDP view do not affect any interfaces bound to VPN instances. When
configuring the transport address of an LDP instance, you must use the IP
address of the interface bound to the VPN instance.
By default, LDP adjacencies on the private network are established using
■
addresses of the LDP-enabled interfaces, while those on the public network are
established using the LDP LSR ID.
Before configuring LDP GR, be sure to complete this task:
Configuring MPLS LDP capability on the devices to be the GR restarter or GR
■
helper
Complete the following configurations on a GR restarter. A GR helper requires no
additional configuration.
n
A single device can act as both GR restarter and GR helper at the same time.
Follow these steps to configure LDP GR:
To do...
Enter system view
Enter MPLS LDP view
Enable MPLS LDP GR
Set the FT reconnect timer
Set the LDP neighbor liveness
timer
Set the LDP recovery timer
Use the command...
system-view
mpls ldp vpn-instance
vpn-instance-name
lsr-id lsr-id
Use the command...
system-view
mpls ldp
graceful-restart
graceful-restart timer
reconnect timer
graceful-restart timer
neighbor-liveness timer
graceful-restart timer
recovery timer
Configuring LDP GR 1333
Remarks
-
Required
Optional
MPLS LSR ID of the LSR by
default
Remarks
-
-
Required
Disabled for MPLS LDP by
default
Optional
300 seconds by default
Optional
120 seconds by default
Optional
300 seconds by default
