PIM-SM 1 belongs to AS 100, while PIM-SM 2 and PIM-SM 3 belong to AS
■
200.
Each PIM-SM domain has zero or one multicast source and one or more
■
receivers. OSPF runs within each domain to provide unicast routes.
PIM-SM 2 and PIM-SM 3 are both PIM stub domains, and BGP or MBGP is not
■
required between these two domains and PIM-SM 1. Instead, static RPF peers
are configured to avoid RPF check on SA messages.
It is required that the respective Loopback 0 of Router C, Router D and Router F
■
be configured as a C-BSR and C-RP of the respective PIM-SM domains.
It is required that Router D and Router F be configured as static RPF peers of
■
Router C, and Router C be configured as the only static RPF peer of Router D
and Router F, so that any router can receive SA messages only from its static
RPF peer(s) and permitted by the corresponding filtering policy.
Network diagram
Figure 339 Network diagram for static RPF peer configuration (on routers)
AS 100
Receiver
Source 1
Router B
Router C
Loop 0
PIM-SM 1
Static RPF peers
Device Interface
Router D POS5/0
Loop0
Router F S2/0
Loop0
Configuration procedure
1 Configure the interface IP addresses and unicast routing protocol for each router
Configure the IP address and subnet mask for each interface as per
Detailed configuration steps are omitted.
AS 200
Router A
Router D
POS 5/0 POS 5/0
IP address Device
192.168.1.2/24 Router C
2.2.2.2/32
192.168.3.2/24
3.3.3.3/32
MSDP Configuration Examples
Receiver
Loop 0
Router G
Router F
Source 3
PIM-SM 3
Receiver
Router E
Loop 0
Source 2
PIM-SM 2
Interface IP address
POS5/0 192.168.1.1/24
S2/0 192.168.3.1/24
Loop0 1.1.1.1/32
Figure
1155
339.
