3Com MSR 50 Series Configuration Manual page 1375

To do...
Create a static route for
forwarding traffic along
an MPLS TE tunnel
n
The interface-type argument in the ip route-static command must be tunnel. In
addition, the preference value must be set.
For more information about static routing, refer to
Routing" on page
Forwarding traffic along MPLS TE tunnels using policy routing
n
Support for this feature varies by device.
Follow these steps to configure policy routing for forwarding traffic along an MPLS
TE tunnel:
To do...
Enter system view
Create and enter the view of
an advanced IPv4 ACL
Define an ACL rule
Exit to system view
Create a policy node and
enter policy-based-route view
Reference the ACL that target
traffic should match
Quit to system view
Enable local policy routing
n
For more information about configuring policy routing, refer to
ACLs" on page 1881
Use command to...
ip route-static dest-address { mask | mask-length }
interface-type interface-number [ gateway-address ] |
vpn-instance d-vpn-instance-name
gateway-address } [ preference preference-value ]
[ tag tag-value ] [ description description-text ]
817.
Use command to...
system-view
acl number acl-number
[ match-order { auto |
config } ]
rule [ rule-id ] { deny |
permit } protocol
[ destination { dest-addr
dest-wildcard | any } |
destination-port operator
port1 [ port2 ] | dscp dscp |
established | fragment |
icmp-type { icmp-type
icmp-code | icmp-message } |
logging | precedence
precedence | reflective |
source { sour-addr
sour-wildcard | any } |
source-port operator port1
[ port2 ] | time-range
time-name | tos tos |
vpn-instance
vpn-instance-name ] *
quit
policy-based-route
policy-name { permit | deny }
node node-number
if-match acl acl-number
quit
ip local policy-based-route
policy-name
and "IP Unicast Policy Routing Configuration" on page
Configuring Traffic Forwarding
Remarks
Required
"Static Routing and Dynamic
Remarks
--
Required
The default ACL rule match
order is config.
Required
--
Required
You may create multiple
policy nodes in one policy
Required
--
Required
"Configuring
1375
639.
