Ftp Server Configuration Example - 3Com MSR 50 Series Configuration Manual

FTP Server Configuration
Example
To do...
Assign a password to
the user
Assign the FTP service
to the user
Specify the directory an
FTP user can access
n
If FTP server performs authentication, authorization and accounting (AAA) policy
on FTP client, AAA related parameters should be configured on the FTP server. For
more information about the local-user, password, service-type, ftp and
work-directory commands and the AAA related configuration, refer to the
"AAA/RADIUS/HWTACACS Configuration" on page
Network requirements
Use your device as an FTP server. Create a user account for an FTP user on it,
■
setting the username to abc and the password to pwd.
The IP address of the Ethernet interface is 1.1.1.1/16.
■
The PC serves as the FTP client.
■
Network diagram
Figure 629 Smooth upgrading using the FTP server
FTP client
1.2.1.1/16
PC
Configuration procedure
1 Configure Device (FTP Server)
# Create an FTP user account abc, setting its password to pwd.
<Sysname> system-view
[Sysname] local-user abc
[Sysname-luser-abc] password simple pwd
# Specify abc to use FTP, and authorize its access to certain directory.
[Sysname-luser-abc] service-type ftp
[Sysname-luser-abc] work-directory cf:/
# Enable FTP server.
Use the command...
password { simple |
cipher } password
service-type ftp
work-directory
directory-name
1.1.1.1/16
Internet
Configuring the FTP Server
Remarks
Required
Required
By default, the system does not
support anonymous FTP access, and
does not assign any service. If the FTP
service is assigned, users can access
the root directory of the device by
default.
Optional
By default, the FTP/SFTP users can
access the root directory of the device.
1751.
FTP server
Device
2111
