11.3.43 McBSP Receive Buffer Status Registers (RBUFFSTAT_REG)
The McBSP_RBUFFSTAT_REG registers are shown and described below.
31
LEGEND: R = Read only; -n = value after reset
Bit Field
31-8 Reserved
7-0 RBUFFSTAT
31
LEGEND: R = Read only; -n = value after reset
Bit Field
31-11 Reserved
10-0 RBUFFSTAT
SPRUGX9 – 15 April 2011
Submit Documentation Feedback
Preliminary
Figure 11-76. McBSP_RBUFFSTAT_REG
Reserved
R-0
Table 11-63. McBSP_RBUFFSTAT_REG Field Descriptions
Value Description
0 Reserved.
0 Receive Buffer Status (indicates the number of occupied locations inside receive buffer).
The RBUFFSTAT value reflects the buffer status on the OCP clock domain and it can be smaller
than the real number of the occupied locations which are seen by the receive state machine.
Figure 11-77. McBSP_RBUFFSTAT_REG
Reserved
R-0
Table 11-64. McBSP_RBUFFSTAT_REG Field Descriptions
Value Description
0 Reserved.
0 Receive Buffer Status (indicates the number of occupied locations inside receive buffer).
The RBUFFSTAT value reflects the buffer status on the OCP clock domain and it can be smaller
than the real number of the occupied locations which are seen by the receive state machine.
© 2011, Texas Instruments Incorporated
8 7
RBUFFSTAT
11 10
RBUFFSTAT
R-0
Multichannel Buffered Serial Port (McBSP)
Registers
0
