11.3.28 McBSP Transmit Channel Enable Register Partition G (XCERG_REG)
The McBSP_XCERG_REG register is shown in
31
Reserved
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Bit Field
31-16 Reserved
15-0 XCERG
11.3.29 McBSP Transmit Channel Enable Register Partition H (XCERH_REG)
The McBSP_XCERH_REG register is shown in
31
Reserved
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Bit Field
31-16 Reserved
15-0 XCERH
11.3.30 McBSP Revision Number Register (REV_REG)
The REV_REG register is shown in
31
LEGEND: R = Read only; -n = value after reset
Bit Field
31-8 Reserved
7-0 REV
SPRUGX9 – 15 April 2011
Submit Documentation Feedback
Preliminary
Figure 11-60. McBSP_XCERG_REG
R-0
Table 11-47. McBSP_XCERG_REG Field Descriptions
Value Description
0 Reserved.
0 Transmit Channel Enable.
XCERG n=0 Disables transmission of n-th channel in an event-numbered block in partition G.
XCERG n=1 Enables transmission of n-th channel in an event-numbered block in partition G.
Figure 11-61. McBSP_XCERH_REG
R-0
Table 11-48. McBSP_XCERH_REG Field Descriptions
Value Description
0 Reserved.
0 Transmit Channel Enable.
XCERH n=0 Disables transmission of n-th channel in an even-numbered block in partition H.
XCERH n=1 Enables transmission of n-th channel in an even-numbered block in partition H.
Figure 11-62
Figure 11-62. McBSP_REV_REG
RESERVED
R-0
Table 11-49. REV_REG Field Descriptions
Value Description
0 Reserved
0 Revision number
© 2011, Texas Instruments Incorporated
Figure 11-60 and described in
16 15
Figure 11-61 and described in
16 15
and described in Table
Multichannel Buffered Serial Port (McBSP)
Registers
Table 11-47.
XCERG
R/W-0
Table 11-48.
XCERH
R/W-0
11-49.
8 7
REV
R-x
0
0
0
