6.3.4.35 PB_CTRL2
Bit Field Value Description
31-8 Reserved 0
7 GAM_EN
0
1
6 GAM_RPT
0
1
5 GEN2_EN
0
1
4 GEN2_RPT
0
1
3 CP_EN
0
1
2 CP_RPT
0
1
1 GEN_EN
0
1
0 GEN_RPT
0
1
SPRUGX9 – 15 April 2011
Submit Documentation Feedback
Preliminary
Table 6-192. PB_CTRL2 Field Descriptions
Reserved
Enable Gamut Metadata InfoFrame transmission on HDMI.
Disabled
Enabled
Repeat Gamut Metadata InfoFrame Packet data each frame.
Disabled (send once after enable bit is set)
Enabled (send in every VBLANK period)
Enable Generic 2 Packet transmission
Disabled
Enabled
Repeat Generic 2 Packet transmission
Disabled (send once after enable bit is set)
Enabled (send in every VBLANK period)
Enable General Control Packet transmission
Disabled
Enabled
Repeat General Control Packet transmission
Disabled (send once after enable bit is set)
Enabled (send in every VBLANK period)
Enable Generic Packet transmission
Disabled
Enabled
Repeat Generic Packet transmission
Disabled (send once after enable bit is set)
Enabled (send in every VBLANK period)
© 2011, Texas Instruments Incorporated
Type
RO
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
High-Definition Multimedia Interface (HDMI)
Registers
