9.4.7 System Test Register (SD_SYSTEST)
This register is used to control the signals that connect to I/O pins when the module is configured in
system test (SYSTEST) mode for boundary connectivity verification.
NOTE: In SYSTEST mode, a write into SD_CMD register will not start a transfer. The buffer
behaves as a stack accessible only by the local host (push and pop operations). In this
mode, the Transfer Block Size (SD_BLK[10:0] BLEN bits) and the Blocks count for current
transfer (SD_BLK[31:16] NBLK bits) are needed to generate a Buffer write ready interrupt
(SD_STAT[4] BWR bit) or a Buffer read ready interrupt (SD_STAT[5] BRR bit) and DMA
requests if enabled.
The system test register (SD_SYSTEST) is shown in
31
15
14
SDCD
SDWP
R/W-0
R/W-0
7
6
D3D
D2D
R/W-0
R/W-0
LEGENDR/W = Read/Write; R = Read only; -n = value after reset
Table 9-17. System Test Register (SD_SYSTEST) Field Descriptions
Bit
Field
Value
31-17
Reserved
16
OBI
15
SDCD
14
SDWP
13
WAKD
Read 0
Write 0
Read 1
Write 1
12
SSB
Read 0
Write 0
Read 1
Write 1
SPRUGX9 – 15 April 2011
Submit Documentation Feedback
Preliminary
Figure 9-35. System Test Register (SD_SYSTEST)
Reserved
R-0
13
12
WAKD
SSB
R/W-0
R/W-0
5
4
D1D
D0D
R/W-0
R/W-0
Description
0
Reserved bit field. Do not write any value. Reads return 0.
Out-of-band interrupt (OBI) data value.
0
The out-of-band interrupt pin is driven low.
1
The out-of-band interrupt pin is driven high.
Card detect input signal (SDCD) data value
0
The card detect pin is driven low.
1
The card detect pin is driven high.
Write protect input signal (SDWP) data value
0
The write protect pin SDWP is driven low.
1
he write protect pin SDWP is driven high.
Wake request output signal data value
No action. Returns 0.
The pin SWAKEUP is driven low.
No action. Returns 1.
The pin SWAKEUP is driven high.
Set status bit. This bit must be cleared prior attempting to clear a status bit of the interrupt status
register (SD_STAT).
No action. Returns 0.
Clear this SSB bit field. Writing 0 does not clear already set status bits.
No action. Returns 1.
Force to 1 all status bits of the interrupt status register (SD_STAT) only if the corresponding bit
field in the Interrupt signal enable register (SD_ISE) is set.
© 2011, Texas Instruments Incorporated
Figure 9-35
and described in
11
10
D7D
D6D
R/W-0
R/W-0
3
2
DDIR
CDAT
R/W-0
R/W-0
Secure Digital (SD)/—Secure Digital I/O (SDIO) Card Interface
Registers
Table
9-17.
17
16
OBI
R/W-0
9
8
D5D
D4D
R/W-0
R/W-0
1
0
CDIR
MCKD
R/W-0
R/W-0
967
