  • Page 1 TMS320C3x Evaluation Module Installation Guide 1993 Microprocessor Development Systems...
  • Page 2 Printed in U.S.A., November 1993, reprinted April 1998 SPRU120...
  • Page 3 TMS320C3x Evaluation Module Installation Guide SPRU120 November 1993 Printed on Recycled Paper...
  • Page 4 IMPORTANT NOTICE Texas Instruments (TI) reserves the right to make changes to its products or to discontinue any semiconductor product or service without notice, and advises its customers to obtain the latest version of relevant information to verify, before placing orders, that the information being relied on is current.
  • Page 5 WARNING This equipment is intended for use in a laboratory test environment only. It generates, uses, and can radiate radio frequency energy and has not been tested for compliance with the limits of com- puting devices pursuant to subpart J of part 15 of FCC rules, which are designed to provide rea- sonable protection against radio frequency interference.
  • Page 6: Table Of Contents

    Installing the Evaluation Module and the C Source Debugger Installing the Evaluation Module and the C Source Debugger This guide helps you install the TMS320C3x evaluation module (EVM) and the C source debugger on a PC running MS-DOS or PC-DOS. You can also use the debugger with MS-Windows.
  • Page 7: What You'll Need

    To minimize the risk of electric shock and fire hazard, be sure that all major components that you interface with Texas Instruments devices are limited in energy and certified by one or more of the following agencies: UL, CSA, VDE, or TUV.
  • Page 8: Software Checklist

    What You’ll Need Software checklist operating system MS-DOS or PC-DOS (version 3.0 or later) Optional: MS-Windows (version 3.0 or later) software tools TMS320 floating-point family DSP (’C3x/’C4x) assembler and linker Optional: TMS320C3x/C4x C compiler † required files evmrst.exe resets the EVM †...
  • Page 9: Step 1: Installing The Evm Board In Your Pc

    Step 1: Installing the EVM Board in Your PC Step 1: Installing the EVM Board in Your PC This section contains the hardware installation information for the EVM. Preparing the EVM board for installation Before you install the EVM board, you must be sure that the board’s switches are set to correctly identify the I/O space that the board can use.
  • Page 10: Setting The Evm Board Into Your Pc

    Step 1: Installing the EVM Board in Your PC Table 1. EVM Board Switch Settings Switch # Address Range default 0x0240–0x025F 0x0280–0x029F 0x0320–0x033F 0x0340–0x035F Some of the other installation steps require you to know which switch settings you used. If you reset the I/O switches, note the modified settings here for later reference.
  • Page 11 Step 1: Installing the EVM Board in Your PC Figure 2. EVM Board Installation mounting bracket rear of computer EVM board 8-bit slot —or— 16-bit slot...
  • Page 12: Step 2: Installing The Debugger Software

    Step 2: Installing the Debugger Software / Step 3: Setting Up the Debugger Environment Step 2: Installing the Debugger Software This section explains the simple process of installing the debugger software on a hard-disk system. 1) Make a backup copy of the DOS and/or MS-Windows debugger product disk.
  • Page 13: Invoking The New Or Modified Batch File

    Step 3: Setting Up the Debugger Environment Figure 3 (a) shows an example of an autoexec.bat file that contains the sug- gested modifications (highlighted in bold type). Figure 3 (b) shows a sample batch file that you could create instead of editing the autoexec.bat file. (For the purpose of discussion, assume that this sample file is named initdb.bat .) The subsections following the figure explain these modifications.
  • Page 14: Setting Up The Environment Variables

    Step 3: Setting Up the Debugger Environment If you are modifying an autoexec that already contains a PATH statement, simply include ;C:\c3xhll at the end of the statement as shown in Figure 3 (a) . If you are creating an initdb.bat file, use a different format for the PATH statement: PATH=C:\C3XHLL;%PATH% The addition of ;%path% ensures that this PATH statement won’t undo...
  • Page 15: Identifying The Correct I/O Switches

    Step 3: Setting Up the Debugger Environment Note that you can override D_OPTIONS by invoking the debugger with the –x option. For more information about options, refer to the invocation section in Chapter 1, Overview of a Code Development and Debugging System , in the TMS320C3x C Source Debugger User’s Guide.
  • Page 16: Step 4: Verifying The Installation

    Step 4: Verifying the Installation Step 4: Verifying the Installation To ensure that you have correctly installed the EVM and debugger software, enter this command at the system prompt: evm30 c:\c3xhll\sample You should see a display similar to this one: Load Break Watch...
  • Page 17: Installation Error Messages

    Step 4: Verifying the Installation / Using the Debugger With MS-Windows Installation error messages While invoking the debugger, you may see the following message: CANNOT INITIALIZE THE EVM ! ! – Check I/O configuration To determine the problem, follow these actions: Check the EVM board to be sure it is installed snugly.
