6.3.4 HDMI_IP_CORE_AUDIO_VIDEO Register Descriptions
Address Offset
04h
08h
0Ch
10h
14h
18h
1Ch
20h
24h
28h
2Ch
50h
54h
60h
64h
6Ch
70h
74h
78h
7Ch
80h
84h
88h
8Ch
90h
BCh
C0h
CCh
D0h
D4h
F0h
F4h
F8h
FCh
100h
104h
108h
10Ch
110h-148h
180h
184h
188h
18Ch
190h-1F8h
200h
204h
SPRUGX9 – 15 April 2011
Submit Documentation Feedback
Table 6-157. HDMI_IP_CORE_AUDIO_VIDEO Registers Summary
Acronym
ACR_CTRL
FREQ_SVAL
N_SVAL1
N_SVAL2
N_SVAL3
CTS_SVAL1
CTS_SVAL2
CTS_SVAL3
CTS_HVAL1
CTS_HVAL2
CTS_HVAL3
AUD_MODE
SPDIF_CTRL
HW_SPDIF_FS
SWAP_I2S
SPDIF_ERTH
I2S_IN_MAP
I2S_IN_CTRL
I2S_CHST0
I2S_CHST1
I2S_CHST2
I2S_CHST4
I2S_CHST5
ASRC
I2S_IN_LEN
HDMI_CTRL
AUDO_TXSTAT
AUD_PAR_BUSCLK_1
AUD_PAR_BUSCLK_2
AUD_PAR_BUSCLK_3
TEST_TXCTRL
DPD
PB_CTRL1
PB_CTRL2
AVI_TYPE
AVI_VERS
AVI_LEN
AVI_CHSUM
AVI_DBYTE__0 - AVI_DBYTE__14
SPD_TYPE
SPD_VERS
SPD_LEN
SPD_CHSUM
SPD_DBYTE__0 - SPD_DBYTE__26
AUDIO_TYPE
AUDIO_VERS
© 2011, Texas Instruments Incorporated
Preliminary
Register Name
ACR Control Register
ACR Audio Frequency Register
ACR N Software Value Register
ACR N Software Value Register
ACR N Software Value Register
ACR CTS Software Value Register
ACR CTS Software Value Register
ACR CTS Software Value Register
ACR CTS Hardware Value Register
ACR CTS Hardware Value Register
ACR CTS Hardware Value Register
Audio In Mode Register
Audio In S/PDIF Control Register
Audio In S/PDIF Extracted Fs and Length Register
Audio In I2S Channel Swap Register
Audio Error Threshold Register
Audio In I2S Data In Map Register
Audio In I2S Control Register
Audio In I2S Channel Status Registers
Audio In I2S Channel Status Registers
Audio In I2S Channel Status Registers
Audio In I2S Channel Status Registers
Audio In I2S Channel Status Registers
Audio Sample Rate Conversion Register
Audio I2S Input Length Register
HDMI Control Register
Audio Path Status Register
Audio Input Data Rate Adjustment Register
Audio Input Data Rate Adjustment Register
Audio Input Data Rate Adjustment Register
Test Control Register
Diagnostic Power Down Register
Packet Buffer Control 1 Register
Packet Buffer Control 2 Register
Packet Registers
Packet Registers
Packet Registers
Packet Registers
Packet Registers
SPD InfoFrame Registers
SPD InfoFrame Registers
SPD InfoFrame Registers
SPD InfoFrame Registers
SPD InfoFrame Registers
Audio InfoFrame Registers
Audio InfoFrame Registers
High-Definition Multimedia Interface (HDMI)
Registers
