Texas Instruments TMS320C66 Series Quick Start Manual

Getting Started
The EVM ships with a Power On Self Test
(POST) flashed into I2C EEPROM. The POST
automatically executes when the board is
powered ON. POST performs memory test
and internal EMAC loopback test. At
power ON, the user LEDs are OFF by
default. The LEDs blink and turn OFF to
indicate successful DSP booting.
After booting, User LED-1 turns ON to
indicate successful RAM test and User
LED-2 turns ON to indicate successful
internal EMAC loop-back test. These LEDs
remain ON to indicate success of both
the tests.
Please refer to the EVM User Guide for
software installation and other details.
Important Notes when handling the
EVM
•Plug in all the cables before powering
ON the EVM to ensure proper grounding.
•Do not unnecessarily flex the boards,
while inserting cables. Excessive flexing
can break the PCB traces.
•Use proper ESD procedures when
handling the EVM.
•Warning: Some components on the EVM
may be too hot to touch with your bare
hand when power is on.
Online Documentation
•TMS320C6670 processor website
http://focus.ti.com/docs/prod/folders/pr
int/tms320c6670.html
•MCSDK website for updates
http://focus.ti.com/docs/toolsw/folders/
print/bioslinuxmcsdk.html
•CCS v5
http://processors.wiki.ti.com/index.php/
Category:Code_Composer _Stu dio_v5
This link contains
•Hardware & Software details
•User Guide
•Technical Reference Manual
•TMS320C6670 Datasheet
