13.4.3 Encoding of LTSSM State in DEBUG Registers
The LTSSM state value that is read from DEBUG registers is an encoded value. The literal names of
the LTSSM states corresponding to the encoded values are tabulated in
Table 13-14. Encoded Debug Registers Contents and Their Relation to
Code
0h
1h
2h
3h
4h
5h
6h
7h
8h
9h
Ah
Bh
Ch
Dh
Eh
Fh
10h
11h
12h
13h
14h
15h
16h
17h
18h
19h
1Ah
1Bh
1Ch
1Dh
1Eh
1Fh
1306
Peripheral Component Interconnect Express (PCIe)
Preliminary
LTSSM States
LTSSM State
DETECTQUIET
DETECTACT
POLLACTIVE
POLLCOMPLIANCE
POLLCONFIG
PREDETECTQUIET
DETECTWAIT
CFGLINKWDSTART
CFGLINKWDACEPT
CFGLANENUMWAIT
CFGLANENUMACEPT
CFGCOMPLETE
CFGIDLE
RCVRYLOCK
RCVRYSPEED
RCVRYRCVRCFG
RCVRYIDLE
L0
L0S
L123SENDEIDLE
L1IDLE
L2IDLE
L2WAKE
DISABLEDENTRY
DISABLEDIDLE
DISABLED
LPBKENTRY
LPBKACTIVE
LPBKEXIT
LPBKEXITTIMEOUT
HOTRESETENTRY
HOTRESET
