www.ti.com
Table 6-31. HDMI_IP_CORE_SYSTEM Registers Summary (continued)
Address Offset
120h
124h
128h
12Ch
130h
134h
138h
13Ch
140h
144h
148h
14Ch
150h
154h
158h
15Ch
160h
164h
168h
16Ch
170h
174h
178h
17Ch
180h
184h
188h
18Ch
190h
194h
198h
19Ch
1A0h
1C0h
1C4h
1C8h
1CCh
1D0h
1D4h
1D8h
1DCh
1E0h
1E4h
240h
244h
248h
24Ch
SPRUGX9 – 15 April 2011
Submit Documentation Feedback
Acronym
VID_CTRL
VID_ACEN
VID_MODE
VID_BLANK1
VID_BLANK2
VID_BLANK3
DC_HEADER
VID_DITHER
RGB2XVYCC_CT
R2Y_COEFF_LOW
R2Y_COEFF_UP
G2Y_COEFF_LOW
G2Y_COEFF_UP
B2Y_COEFF_LOW
B2Y_COEFF_UP
R2CB_COEFF_LOW
R2CB_COEFF_UP
G2CB_COEFF_LOW
G2CB_COEFF_UP
B2CB_COEFF_LOW
B2CB_COEFF_UP
R2CR_COEFF_LOW
R2CR_COEFF_UP
G2CR_COEFF_LOW
G2CR_COEFF_UP
B2CR_COEFF_LOW
B2CR_COEFF_UP
RGB_OFFSET_LOW
RGB_OFFSET_UP
Y_OFFSET_LOW
Y_OFFSET_UP
CBCR_OFFSET_LOW
CBCR_OFFSET_UP
INTR_STATE
INTR1
INTR2
INTR3
INTR4
INT_UNMASK1
INT_UNMASK2
INT_UNMASK3
INT_UNMASK4
INT_CTRL
XVYCC2RGB_CTL
Y2R_COEFF_LOW
Y2R_COEFF_UP
CR2R_COEFF_LOW
© 2011, Texas Instruments Incorporated
Preliminary
Register Name
Video Control Register
Video Action Enable Register
Video Mode1 Register
Video Blanking Registers
Video Blanking Registers
Video Blanking Registers
Deep Color Header Register
Video Mode2 Register
RGB_2_xvYCC control Register
RGB_2_xvYCC Conversion R_2_Y Register
RGB_2_xvYCC Conversion R_2_Y Register
RGB_2_xvYCC Conversion G_2_Y Register
RGB_2_xvYCC Conversion G_2_Y Register
RGB_2_xvYCC Conversion B_2_Y Register
RGB_2_xvYCC Conversion B_2_Y Register
RGB_2_xvYCC Conversion R_2_Cb Register
RGB_2_xvYCC Conversion R_2_Cb Register
RGB_2_xvYCC Conversion G_2_Cb Register
RGB_2_xvYCC Conversion G_2_Cb Register
RGB_2_xvYCC Conversion B_2_Cb Register
RGB_2_xvYCC Conversion B_2_Cb Register
RGB_2_xvYCC Conversion R_2_Cr Register
RGB_2_xvYCC Conversion R_2_Cr Register
RGB_2_xvYCC Conversion G_2_Cr Register
RGB_2_xvYCC Conversion G_2_Cr Register
RGB_2_xvYCC Conversion B_2_Cr Register
RGB_2_xvYCC Conversion B_2_Cr Register
RGB_2_xvYCC RGB Input Offset Register
RGB_2_xvYCC RGB Input Offset Register
RGB_2_xvYCC Conversion Y Output Offset Register
RGB_2_xvYCC Conversion Y Output Offset Register
RGB_2_xvYCC Conversion CbCr Output Offset Register
RGB_2_xvYCC Conversion CbCr Output Offset Register
Interrupt State Register
Interrupt Source Register
Interrupt Source Register
Interrupt Source Register
Interrupt Source Register
Interrupt Unmask Register
Interrupt Unmask Register
Interrupt Unmask Register
Interrupt Unmask Register
Interrupt Control Register
xvYCC_2_RGB Control Register
xvYCC_2_RGB Conversion Y_2_R Register
xvYCC_2_RGB Conversion Y_2_R Register
xvYCC_2_RGB Conversion Cr_2_R Register
High-Definition Multimedia Interface (HDMI)
Registers
735
