Registers
6.3.4.44 SPD_CHSUM
Bit Field Value Description
31-8 Reserved 0
7-0 SPD_CHSU 0
M
6.3.4.45 SPD_DBYTE__0-SPD_DBYTE__26
Table 6-202. SPD_DBYTE__0-SPD_DBYTE__26 Field Descriptions
Bit Field Value Description
31-8 Reserved 0
7-0 SPD_DATA 0
6.3.4.46 AUDIO_TYPE
Bit Field Value Description
31-8 Reserved 0
7-0 AUDIO_TYP 0
E
6.3.4.47 AUDIO_VERS
Bit Field Value Description
31-8 Reserved 0
7-0 AUDIO_VER 0
S
830
High-Definition Multimedia Interface (HDMI)
Preliminary
Table 6-201. SPD_CHSUM Field Descriptions
Reserved
SPD InfoFrame Checksum. SPD_HDR[31:24]
Reserved
SPD InfoFrame Data Bytes.
Table 6-203. AUDIO_TYPE Field Descriptions
Reserved
AUDIO InfoFrame Type Code. AUDIO_HDR[7:0]
Table 6-204. AUDIO_VERS Field Descriptions
Reserved
AUDIO InfoFrame Version Code. AUDIO_HDR[15:8]
© 2011, Texas Instruments Incorporated
www.ti.com
Type
RO
R/W
Type
RO
R/W
Type
RO
R/W
Type
RO
R/W
SPRUGX9 – 15 April 2011
