13.4.4.54 IB_START3_LO Register

The inbound translation 3 start address low register (IB_START3_LO) is described in the figure and
table below.
31
7
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Bit Field
31-8 IB_START3_LO
7-0 Reserved

13.4.4.55 IB_START3_HI Register

The inbound translation 3 start address high register (IB_START3_HI) is described in the figure and
table below.
31
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Bit Field
31-0 IB_START3_HI
SPRUGX9 – 15 April 2011
Submit Documentation Feedback
Preliminary
Figure 13-66. IB_START3_LO Register
IB_START3_LO
Reserved
Table 13-69. IB_START3_LO Register Field Descriptions
Value Description
0-FF FFFFh Start address bits 31-8 for inbound translation region 3
0 Reserved
Figure 13-67. IB_START3_HI Register
IB_START3_HI
Table 13-70. IB_START3_HI Register Field Descriptions
Value Description
0-FFFF FFFFh Start address bits 63-0 for inbound translation region 3
© 2011, Texas Instruments Incorporated
R/W-0
R-0
R/W-0
Peripheral Component Interconnect Express (PCIe)
Registers
8
0
0
1337
