14.7.6.2 CM_DEFAULT_L3_FAST_CLKSTCTRL Register

The CM_DEFAULT_L3_FAST_CLKSTCTRL register enables the domain power state transition. It
controls the software supervised clock domain state transition between ON-ACTIVE and ON-INACTIVE
states. It also holds one status bit per clock input of the domain.
31
15 10
Reserved CLKACTIVITY_DDR_GCLK
R-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 14-70. CM_DEFAULT_L3_FAST_CLKSTCTRL Register Field Descriptions
Bit Field
31-10 Reserved
9 CLKACTIVITY_DDR_GCLK
8 CLKACTIVITY_L3_FAST_GCLK
7-2 Reserved
1-0 CLKTRCTRL
