LIST OF TOOLS

6.1

Tools

No. Adjustment Item
1 Pen force adjustment
2 Distance adjustment
3 Pen block height adjustment
4 Firmware update
5 X-drive belt tension adjustment
6 Y-drive belt tension adjustment
7 Replacing the parts
8 Removing the cap screws
6.2

Greasing And Gluing Points

No. Grease or Glue Point
1 Cam
2 X-drive motor pulley
3 Y-drive motor pulley
4 X-drive pulley
5 Y-drive pulley
6 Y-tension pulley
7 Y-motor drive pulley set screws
8 X-motor drive pulley set screws
9 X-drive pulley set screws
CE7000-UM-251-9370
Jig
Cutter Pen Holder (CB09) Colex gauge (50,300,500 gf)
10 mm height block
Grease or Glue name
Shinetu silicon grease G501
Shinetu silicon grease G501
Shinetu silicon grease G501
Shinetu silicon grease G501
Shinetu silicon grease G501
Shinetu silicon grease G501
Loctite 222
Loctite 222
Loctite 222
6-1
6
Tool
Scale (at least 400 mm long)
Scale (at least 50 mm long)
PC, USB I/F cable
Push-pull gauge (2 kg)
Push-pull gauge (2 kg)
Screwdriver
Allen Wrench
Application quantity
Suitable quantity
Suitable quantity
Suitable quantity
Suitable quantity
Suitable quantity
Suitable quantity
Small quantity
Small quantity
Small quantity
LIST OF TOOLS
