Error
Error Display
code
E01014
E01015
E01017
CE7000-UM-251-9370
Verification item
X or Y motor is
defective.
Or the main board is
defective.
Check the media.
Load on the X motor
When the heavy roll
was too large.
media is fed from the
roll, was this error
shown?
Confirm the cutting
Media is thick and
conditions.
hard.
Is there anything
Movement of the X is
blocking the X
being obstructed.
movement?
Confirm the X motor
The power cable or
cables securely
the encoder cable
connected.
for the X motor is not
Confirm the X motor
connecting to correct
cables are connecting
connector on the
to the correct
main board.
connector.
Are the X motor
The power cable or
cables broken?
the encoder cable
for the X motor is
broken.
Does the X-motor
Defective X motor or
rotate smoothly?
Defective Main Board
Confirm the serial
number for the plotter,
and guess how long
this motor was used.
9-13
9
TROUBLESHOOTING
Cause
Solution
Replace the X or Y
motor.
Or replace the main
board.
Do not use heavy roll
media.
Use the pre-feed
function when the roll
media is using.
Lower the cutting
SPEED and/or the
cutting FORCE.
And cut it by multi pass.
Turn off the plotter,
remove the obstacle,
then turn the plotter
back on.
Use the basket.
Connect the X motor
cables securely.
Connect the X motor
cables to correct
connector.
Replace the X motor
cables if it is defective.
Replace the X-motor if it
is defective.
Replace the main board
when the problem
remained even if
X-motor was replaced.
