10.7 Main Electrical Parts CE7000-40/60

No. Part No.
U792700700 Main Board, CE7, PN6043-01
1
U792700710 Main Board, CE7RS-232, PN6043-01
2 U79 Cable, Cam Sensor Flexible Cable CE70
3 U792900735 Cam Sensor Board, PN5122-06
4 U692184273 Y Flexible Cable, FFC604301, 40/60
5 U361102011 Flexible Cable Tie, RFC-45V0
6 U621843435 Flexible Cable Tie, FFC-CLIP-CEN
7 U792700730 Y Relay Board CE70-40/60, PN6043-04
8 U561500100 AC Inlet, R-301(02)
9 U692184000 Cable, CA604300
10 U692184010 Cable, CA604301
11 U692180021 Cable, CA512202A
12 U561630088 Switch, Power, AJ7W202BF
13 U692180031 Cable, CA512203A
14 U562500141 Power Supply, ZWS150B-24/FV
15 U692184072 Cable, CA604307B
16 U682180270 Fan, 9A0924G404
17 U561080035 Media Sensor, PS117EL1
18 U692180174 Cable, CA512217D, Media Sensor
19 U682157211 Motor, DMN37JE-010
20 U621802114 Pulley, Motor, S2M024-ASSY
21 U692180114 Cable, CA512211D
22 U692180092 Cable, CA512209B
23 U621844200 Cover, Motor Cover
U621800170 Plate, Cover RS-232C hole
24
U692180223 RS-232C Connector Cable, CA512222C
25 U621840282 Bracket, Media Sensor
