1.1.2

CE7000-130AP Main Specifications

CPU
Configuration
Drive
Max. cutting area
Guaranteed precision cutting area
Mountable media width
*3
Available roll media diameter
Number of push rollers
Max. cutting speed (Axial)
Specifiable speeds
Max. cutting force
Min. character size
Mechanical resolution
Programmable resolution
Repeatable accuracy
*1
Number of cutters/pens
Usable pen types
Compatible media
Interfaces
Buffer memory
Resident command sets
LCD Panel
Power supply
Power consumption
Operating environment
Guaranteed accuracy environment
External dimensions (W x D x H)
Weight (Approx.)
*4
*1: Varies depending on the type of Graphtec-authorized film and the cutting conditions.
*2: When using basket.
*3: HP-GL is a registered trademark of the US Hewlett Packard Company.
*4: Stand and basket are included.
*5: RS-232C interface is optional depending on region. For details, please contact the distributor where you purchased.
CE7000-UM-251-9370
32-bit
Grit-rolling plotter
Digital servo
1220 mm x 50 m
1200 mm x 3 m
*1 *2
Min. 594 mm
Max. 1321 mm
Max. diameter: 200 mm, 3-inch paper core roll only
5
600 mm/sec(Omnidirectional)
1 to 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60 cm/sec
Tool holder: 4.41N (450gf)
Pen holder: 2.94N (300gf)
5 mm (0.197 in) alphanumeric Helvetica med. Font
0.005mm
GP-GL: 0.1/0.05/0.025/0.01 mm, HP-GL
0.1 mm/in unit of 2 m (Designated Film and Cut Conditions)
2
Water-based fiber-tip pen, oil-based ballpoint pen
Mono-vinyl chloride media, fluorescent media, and reflective media up to 0.25
mm thick (Excluding the high reflective media)
USB2.0 (Full Speed)/Network (Ethernet 10BASE-T/100BASE-TX)/RS-232C
2 MB
GP-GL/HP-GL (Control panel switching, Auto switching)
*3
Graphic type (240 x 128 dots)
AC100-120V, AC200V-240V 50/60Hz
100 VA or less
Temperature: +10˚C to +35˚C
Humidity: 35% to 75% (non-condensing)
Temperature: +18˚C to +28˚C
Humidity: 40% to 65%(non-condensing)
1704 x 1148 x 1215 mm
59.4 kg
CE7000-130AP
: 0.025 mm
*4
1-2
1 INTRODUCTION
*1
*5
