10.12 Y Drive Part CE7000-130/130AP/160

No. Part No.
1 U682157211 Motor, DMN37JE-010
2 U621802114 Pulley, Motor, S2M024-ASSY
3 U692180114 Cable, CA512211D
4 U692180092 Cable, CA512209B
U792700815 Belt, Y, 200S2M1615LW-C
5
U792700820 Belt, Y, 200S2M1827LW-C
6 U621863242 Pulley, Y Drive, Pulley Assey
7 U378012421 Belt, Motor, STS-60S2M248_124Z-R
8 U621800774 Dog, Cam Sensor
9 U621860791 Spring, Cam Shaft, CE70-130/160
10 Bush, C4L5
11 U792900735 Cam Sensor Board, PN5122-06
12 U621863203 Bracket, Y Drive Bracket CE70-130/160
13 U361102011 Flexible Cable Tie, RFC-45V0
14 U621803211 Plate, Y Drive Adjust Plate
15 U380287311 Spring, DS8731
16 U621863313 Bracket, Y Tension Arm, CE70-130/160
17 Bush, C4L50
18 U621863353 Shaft, Idler Pulley, CE70-130/160
19 U621803323 Pulley, Y Tension Pulley
20 U310068620 Roller B, 686ZZMC3PS2S
21 Bush, C6L3
22 U692180322 Flexible Cable, FFC512206B
23 U621843452 Bracket, Push Roller Sensor
24 U792700740 Push Roller Sensor Board, PN6043-04
25 U621843421 Plate, Y Belt Stopper Plate, CE70
Y Drive Part CE7000-130/130AP/160
18
19
21
20
CE7000-UM-251-9370
Description
17
16
15
5
23
22
24
Q'ty
2
2
2 Motor Encoder Cable
2 Motor Extension Cable
CE7000-130/130AP
1
CE7000-160
1
1
1
1
1
2
1
1
1
1
1
1
2
2
1 Push Roller Sensor
1
1
2
14
25
7
2
1
3
10-13
10 PARTS LIST
Remarks Rank
A
C
C
C
A
A
A
A
A
D
A
D
D
D
A
D
D
D
C
C
D
A
C
A
C
12
13
11
10
9
8
6
5
4
