Upgrading the System Firmware

To upgrade the system firmware, prepare the following items.
CE7000-40/60/130/160
• Windows PC
• USB cable
• CE7000_V***_R****.X
• SEND.EXE
• OPS662
CE7000-130AP
• Windows PC
• USB cable
• CE7000AP_V***_R****.X
• SEND.EXE
• OPS628
Preparation
(1) Copy the firmware file onto the PC.
(2) Copy the SEND.EXE onto the PC.
(3) Install the Windows Driver to the PC before connecting the CE7000 to the PC.
(4) Connect the PC and CE7000 via the USB port after the Windows driver was installed.
How to upgrade the system firmware
(1) Turn off the power for the CE7000 if power was turned on.
(2) Turn on the power while pressing the LEFT and RIGHT position keys.
Or after turning on the power, press the LEFT and the RIGHT position key simultaneously within 2
seconds.
(3) The plotter displays the following menu.
CE7000-UM-251-9370
:The firmware is able to update from the Windows PC only.
:CE7000 firmware
:Utility to transfer files using Windows
:USB Driver software for the CE7000 (version must later than V3.70.)
:The firmware is able to update from the Windows PC only.
:CE7000AP firmware
:Utility to transfer files using Windows
:USB Driver software for the CE7000AP (version must later than V10.30.)
®
®
