3.1.4

Parts Names and Functions for CE7000-130AP

Front View
Grit roller position guide
Cutting mat
Grit rollers
Power switch
Power switch����������������������������Used to turn the plotter on and off�
Control panel ���������������������������Used to access various plotter functions�
Push rollers ������������������������������Rollers that push the media against the grit rollers�
Grit rollers ��������������������������������Feeds the media back and forth�
Media sensors��������������������������The front sensor is used to sense the leading edge of the media� The rear
Tool carriage ����������������������������Moves the cutter-pen or plotting pen across the media during cutting or
Tool holder �������������������������������Holds the cutter-pen or plotting pen and moves it up or down�
Grit roller position guide ���������A roller position guide is affixed to the front side of the rail, which shows the
Cutting mat �������������������������������The oil-base ballpoint moves above this and does the cutting/plotting�
Media set lever �������������������������Used to raise or lower the Push rollers during the loading or unloading of
Media stocker���������������������������The stock shaft is set�
Media stopper ��������������������������This stops the stock shaft from spinning when setting in media� It is utilized
CE7000-UM-251-9370
Tool holder
Tool carriage
Media guide
Stock shaft
Push rollers
sensor is used to sense the trailing edge of the media�
plotting�
position of each grit roller� Use these alignment marks as an aid in locating
the Push rollers�
media�
when pulling roll media straight out�
3 PARTS NAMES and FUNCTIONS
Pen holder
Media sensors
Control panel
Media set lever
3-7
Pen station
Media stopper
Media stocker
