10.8 Main Electrical Parts CE7000-130/130AP/160

No. Part No.
U792700700 Main Board, CE7, PN6043-01
1 U792700710 Main Board, CE7RS-232, PN6043-01
U792700825 Main Board, CE7-130AP, PN6043-01
2 U79 Cable, Cam Sensor Flexible Cable CE70
3 U792900735 Cam Sensor Board, PN5122-06
4 U692184293 Y Flexible Cable, FFC604303, 130/160
5 U361102011 Flexible Cable Tie, RFC-45V0
6 U621843432 Flexible Cable Tie, FFC-CLIP-CEN
7 U792700730 Y Relay Board CE70-40/60, PN6043-04
8 U561500100 AC Inlet, R-301(02)
9 U692184000 Cable, CA604300
10 U692184010 Cable, CA604301
11 U692180021 Cable, CA512202A
12 U561630088 Switch, Power, AJ7W202BF
13 U692180031 Cable, CA512203A
14 U562500141 Power Supply, ZWS150B-24/FV
15 U692184072 Cable, CA604307B
16 U682180270 Fan, 9A0924G404
17 U692180133 Cable, CA512213C, FAN 1
18 U692180143 Cable, CA512214C, FAN 2
19 U561080035 Media Sensor, PS117EL1
20 U692180174 Cable, CA512217D, Media Sensor
21 U692180114 Cable, CA512211D
22 U692180092 Cable, CA512209B
U621800170 Plate, Cover RS-232C hole
23
U692180223 RS-232C Connector Cable, CA512222C
24 U621804182 Bracket, Power Switch
25 U621864081 Cover, Power Switch
Main Electrical Parts CE7000-130/130AP/160
14
13
12
25
15
CE7000-UM-251-9370
Description
9
8
10
11
24
16
7
18
19
20
Q'ty
1
1 Option for Japanese and Chinese model only.
1 CE7000-130AP
1 Cam sensor
1
1
2
1
1
1 AC_INLET to SW (Brown)
1 AC_INLET to SW (Blue)
1 AC_INLET to FG (Green)
1
1 SW to POWER SUPPLY
1
1 POWER SUPPLY to MB
1
1
1
2
1
2 Motor Encoder Cable
2 Motor Extension Cable
1
1 Option for Japanese and Chinese model only.
1
1
6
19
20
23
16
21
17
10-8
10 PARTS LIST
Remarks
5
4
3
2
1
23
20
17
18
22
15
Rank
A
A
A
A
A
A
D
D
A
C
C
C
C
C
C
A
C
A
C
C
A
C
C
C
C
C
D
D
