Rear View
Roll-medium tray ���������������������A tray to set media in�
Roll-medium tray guide rail ����A rail to set the roll media tray in�
Power switch����������������������������Used to turn the plotter on and off�
AC line inlet ������������������������������Inlet where the power cable is connected�
Accessory case �����������������������Space for temporary storage of accessories such as cutter blades and cutter
CE7000-UM-251-9370
Accessory case
Roll-medium tray
Roll-medium tray
guide rail
plungers�
3-2
3 PARTS NAMES and FUNCTIONS
Media sensors
Power switch
AC line inlet
