9.3

Cutting Operations

Symptom
The cut line is crooked.
The blade skips and
does not completely
cut lines that should be
solid.
When it is cutting with
the same condition, a
part of cutting line is not
cut.
It does not cut more than
2 m long length.
The cutting position
shifts to the 5 mm front.
CE7000-UM-251-9370
Verification item
Does the blade smoothly rotate in the
blade holder?
Is the tip of blade broken?
Is there the deep scratches on the
cutting mat?
Is the CB09 blade installing to the
correct blade holder?
Is the belt tension of X or Y drive
motor loose?
Is the pulley of X or Y motor fixing to
the motor shaft securely?
Is there any play between the Y slider
roller and the Y rail?
Is the tool installed to correct
position?
Is not the blade length too long?
Is not the cutting speed too fast?
Is not the pen force too low?
Confirm the pen block height.
The pen block height must be 10 mm
from the cutting mat.
Is the tool installed to correct
position?
Confirm the pen block height.
The pen block height must be 10 mm
from the cutting mat.
Default page length is 2 m, therefore
it does not cut more than 2 m when
the page length is default setting.
Confirm the tool holder is installing to
the correct position.
Replace the blade holder to new one if
the blade does not smoothly.
Replace the blade to new one if the tip of
blade is broken.
Replace the cutting mat to new one if
there is the deep scratches on the cutting
mat.
Use the blade holder of CB09 blade if
the blade holder of CB15 is used.
Adjust the belt tension if it is loose.
Tighten the screw of pulley if it is not
securely tighten.
Adjust the Y slider roller tension.
Attach tool plunger correctly.
The tool stopper must cover the upper
flange of tool plunger.
Adjust the blade length.
Adjust the speed setting.
Adjust the pen force.
Adjust the pen block height to 10 mm
from the cutting mat.
Attach tool plunger correctly.
The tool stopper must cover the upper
flange of tool plunger.
Adjust the pen block height to 10 mm
from the cutting mat.
Set the page length to more than 2 m in
the MEDIA SETTING menu.
PAUSE/MENU --> 4 MEDIA --> 3 PAGE
LENGTH --> Set the page length which
you want to cut the length.
Install the tool holder to the rear of
holder.
9-5
9 TROUBLESHOOTING
Solution
