Stand For Ce7000-130/160 (St0119/0120) - GRAPHTEC CE7000-40 Service Manual

10.16 Stand for CE7000-130/160 (ST0119/0120)

No. Part No.
1 U621861532 Foot Assembly, CE70-130/160
U792900775 Caster, NANSIN, DNB50B M8
U621590381 End Cap, CE6-120
2 U621861523 Side Stay, CE70-130/160
U621861512 Center Bar, Stand CE70-130
3
U621871510 Center Bar, Stand CE70-160
4 U792700915 Right Stocker Bracket Assy, CE7-130/160
5 U792700920 Left Stocker Bracket Assy, CE7-130/160
U621861040 Stocker Shaft Assembly CE70-130
6
U621871040 Stocker Shaft Assembly CE70-160
U621590361 End Cap, 120CE6
U621861050 Stocker Shaft CE70-130
U621871050 Stocker Shaft CE70-160
7 U621801390 Stopper Assembly Guide Ring
U621590432 Stopper Ring, PAPER-POSITION
M4L15 High Pick Screw
Nut, M4
M4L16 Binding Head Screw
Bush, C4L6
8 U621861130 Brake, CE7 Stocker Shaft Brake
9 U621801380 Roller B, KTM, Stocker
Stand for CE7000-130/160 (ST0119/0120)
CE7000-UM-251-9370
Description
5
3
2
1
Q'ty
2
(4) NANSHIN, DNB50B M8
(8)
2
CE7000-130
1
CE7000-160
1
1
CE7000-130
2
CE7000-160
(4)
(2) CE7000-130
(2) CE7000-160
2
(4)
(2)
(2)
(2)
(2)
(2)
(10)
6
6
10-17
10 PARTS LIST
Remarks Rank
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
D
D
D
D
C
C
7
4
2
1
