Upgrading G3rV4 and R5/6/7/8r to Avaya DEFINITY
Server R running Avaya Communication Manager
Figure Notes
1. Not Write-protected
Figure 2-2. Make sure the optical disk is not write protected
5. Place the removable media (optical disk) containing the Avaya
Communication Manager, label facing left, into the optical drive in SPE B.
The arrow should be in the top left position when inserting the cartridge into
the drive.
!
CAUTION:
The removable media has a sliding, metal cover to protect the surface
of the disk. DO NOT TOUCH THE DISK UNDER THE METAL
COVER
2-26
Issue 7 November 2003
2. Write protected
(Figure 2-3).
1 2
h1dfdsk KLC 112499
555-233-115
