Install the EPN

Install TDM/LAN Bus Terminators

1. If the Release 5/6si PPN has only 1 cabinet, install the 2 AHF110
TDM/LAN bus terminators per
Figure Notes
1. Expansion Cabinet (A Position)
2. AHF110 TDM LAN/Bus Terminator
(Slot 18)
Figure 4-2. TDM/LAN Bus Terminators for Single-Carrier Cabinet EPN
2. If the Release 5/6si PPN has more than 1 cabinet:
a. Install the AHF110 TDM/LAN bus terminator in Slot 03 on the right
b. Install the other AHF110 TDM/LAN bus terminator on the top port
555-233-115
side of the expansion control cabinet as shown in
cabinet, at the end of the daisy chain of the bus.
Figure 4-2.
3. AHF110 TDM LAN/Bus Terminator
(Slot 01)
Issue 7 November 2003
Figure 4-3.
4-23
