Install the EPN

Connect TDM/LAN Cables and ICC Cables

1. Route and connect the TDM/LAN cables. If any of the Release 5/6si port
cabinets were originally R1V3 port cabinets, use the following steps to
route a cable between an R1V3 upper cabinet and cabinet beneath it. Do
not run a new cable through the existing slot in the rear shelf of the upper
cabinet.
a. Loosen the 2 left connector panel screws, then remove the other 2
b. Attach the TDM/LAN cable to the backplane and slide the cable
c. Replace and tighten the connector panel screws.
2. For a critical reliability system, connect the ICC cables as shown in
4-6, Figure
NOTE:
For a duplicated cabinet, do not use the ICC cables (H600-259 G1)
removed from the duplicated Release 5/6si PPN. Use the new ICC
cables (H600-248 G1) supplied with the upgrade.
Table 4-6. Intercabinet Cable Connections
EPN J58890N
3. On the A carrier, verify the CFY1 current limiter (CURL) connects to pinfield
block 00 (see
555-233-115
connector panel screws.
between the connector panel and the rear shelf (not through the
existing slot in the shelf). Route the cable along the bottom of the
cabinet.
4-4, and Figure 4-5.
Connect ICC Cables
From
Carrier Pin-Field Block
ICCA
ICCB
Figure 4-4).
To
Carrier Pin-Field Block
J58890H ICCA
ICCB
Issue 7 November 2003
Table
4-25
