Adding or Removing Cabinet Hardware

Add DID Trunks

Requirements
Each Direct Inward Dial (DID) trunk connects to 1 port DID Trunk circuit pack or to
1 port of an assortment of DID trunk circuit packs.
Installation
1. Determine the port assignment of the trunk from the Trunk Group form.
EXAMPLE:
2. Install a DID Trunk circuit pack in assigned carrier slot (if an additional
circuit pack is required).
3. Administer forms listed under "DID Trunk Group" in Administrator's Guide
for Avaya Communication Manager.

Add Tie Trunks

Requirements
Each tie trunk connects to 1 port of a 4-port tie trunk circuit pack or to an
assortment of international tie trunk circuit packs.
Installation
1. Determine the port assignment of the trunk from the trunk group screen.
EXAMPLE:
2. Install the tie trunk or an international tie trunk circuit pack in assigned
carrier slot (if an additional circuit pack is required).
3. For customer-owned (not leased) tie-trunk facilities (such as campus
environments), tie trunk circuit packs provide signaling capabilities beyond
those specified by the industry-wide E&M standard. Use
Table 7-6
circuit pack, and administer the port.
7-26
Issue 7 November 2003
3 A
Cabinet (Port Carrier
Network)
3 A
Cabinet (Port Carrier
Network)
to choose the preferred signaling format, set switches on the
07 01
Slot Port
Number Number
07 01
Slot Port
Number Number
Figure 7-1
555-233-115
and
