Add IP Solutions
Check your Shipment
When the shipment arrives, check the contents (see
1. Inspect the shipping carton for damage before opening it. If the box is
damaged, do not open it. Inform the shipping company, and ask for
instructions on filing a claim.
2. If the box is undamaged, check the contents against the packing slip.
Check the condition of each component, and note any damage or
shortages on the packing slip. The carton should contain the following for
each IP Interface ordered:
Table 7-11. Required Hardware
Comcode/Code
108525528
J58890MA-1 L30
601939804
407633999
601087091
3. Read and follow any directions inserted into the package by the factory.
The TN802B external cable assembly is a bundle of cables with an amphenol
connector at the end of the bundle and various PC-type connectors (VGA,
Universal Serial Bus [USB], mouse, keyboard, Ethernet, modem, and COM2) at
the ends of the individual cables. See
bundle enters the amphenol connector.
555-233-115
Description
TN799B C-LAN circuit pack. One
TN799B supports more than one
TN802B.
TN802B IP Interface Assembly
H600-512,G1 external cable
assembly
259A connector
CAT5 or better cable
U.S. Robotics Sportster external
modem, Model USR 33.6 EXT (U.S.
customers only). Non-U.S.
customers must provide a modem
comparable to this model.
20-ft DB-25 serial cable from modem
to TN802B external cable assembly
(U.S. customers only). Non-U.S.
customers must provide a serial
cable.
Figure 7-9. Look for the label where the
Table 7-11).
Quantity
1
1 or more
1 or more
1
1
1
1
