Avaya DEFINITY Server R Manual page 308

Upgrading a Multicarrier G2 Universal Module to Avaya
DEFINITY Server R EPN running Avaya Communication
Manager
Figure Notes
1. Lightwave Transceiver
2. To PPN Carrier A Slot 1A02
3. To EPN2 Carrier A Slot 3A01
4. To PPN Carrier B Slot 1B02
Figure 5-30. Fiber Optic Connections PPN to EPN2
5-118
Issue 7 November 2003
RX TX
4 3
RX TX
2 1
4 3
2 1
cydff06 CJL 103196
5. To EPN2 Carrier A Slot 3A01
6. Fiber Optic Cable
7. TX Connector
8. RX Connector
555-233-115
