Upgrading a Multicarrier G2 Universal Module to Avaya
DEFINITY Server R EPN running Avaya Communication
Manager
Remove Module Control Carrier A
Disconnect TDM/LAN Cables
NOTE:
Note the position of the TDM/LAN cables before disconnecting.
1. Disconnect 1 end of the TDM/LAN cable (between the "A" and "C" carriers)
from the "A" carrier. See
2. Disconnect 1 end of the TDM/LAN cable (between the "A" and "D" carriers)
from the "A" carrier.
!
WARNING:
When removing the TDM/LAN cables from a previously upgraded
carrier, be careful that none of the short pieces of shrink tubing come
off the 4 corner pins of the pin-field block. Otherwise, when the new
equipment is connected, -48 volts could short to ground.
3. On port carrier J58890BB-1, connect the TDM cable or TDM terminator to
Slot 02. On port carriers J58890BB-2 and J58890BB-3, connect the TDM
cables to Slot 01.
