Installing TN464GP/TN2464BP with Echo Cancellation

Installing TN464GP/TN2464BP
with Echo Cancellation
The TN464GP and TN2464BP circuit packs with echo cancellation are intended
for customers who are likely to encounter echo over circuits connected to the
Direct Distance Dialing (DDD) network. These circuit packs are intended for
channels supporting voice; therefore, they support the following trunks: CAS, CO,
DID, DIOD, DMI, FX, Tie, WATS. They do not support any data trunk groups.
NOTE:
The P suffix designation means the circuit pack is programmable; new
firmware can be downloaded directly to the circuit pack.
The TN464GP and TN2464BP circuit packs are backwards compatible, although
the echo cancellation feature can only be used with Release 1.1 or later of
Avaya™ Communication Manager and after the feature is enabled.
The echo cancellation feature cancels echoes with delays up to 96 ms. Echo
cancellation is disabled automatically when the circuit pack detects a 2100-Hz
phase-reversed tone put out by high-speed modems (56 kbaud) but not when it
detects a 2100-Hz straight tone generated by low-speed modems (9.6 kbaud).
For information on installing port circuit packs, refer to Installing Port Circuit
Packs. For information on setting the option switches, refer to Option Switch
Settings. For information on administering the circuit packs, refer to the
Administrator's Guide for Avaya Communication Manager.
Echo cancellation must first be purchased, then activated by someone with
customer options login privileges. Refer to the Administrator's Guide for Avaya
Communication Manager.
Use the following procedure to modify the settings:
NOTE:
You do not need to busyout the circuit packs to modify the settings. But the
modified settings do not take effect until either the port is busied out or the
scheduled maintenance runs.
1. Type display system-parameters customer-options and press
screen 2 verify that the DS1 Echo Cancellation? field is set to y . If
not, contact your Avaya representative as this must be set by the license
file.
2. Type [add | change] trunk-group [next | number] and press
