Interconnect Port Networks with Fiber Optic Cabling
For Two Collocated Expansion Port Networks
1. Behind control carrier A of PPN cabinet 1:
2. Behind control carrier A of EPN cabinet 3:
3. Behind control carrier A of EPN cabinet 2:
555-233-115
Install a lightwave transceiver on cable connector at slot 1A02.
NOTE:
Attenuators may be required for single mode fiber using a
300A Lightwave Transceiver
Connect 1 end of the fiber optic cable to the lightwave transceiver,
just installed, at slot 1A02.
Carefully attach the fiber optic cable (with cable ties) to the wall of
the cable tray at the built-in cable tie positions.
Install a lightwave transceiver on cable connector at slot 3A01.
NOTE:
Attenuators may be required for single mode fiber using a
300A Lightwave Transceiver
Connect the other end of the fiber optic cable to the lightwave
transceiver, just installed, at slot 3A01.
Carefully attach the fiber optic cable (with cable ties) to the wall of
the cable tray at the built-in cable tie positions.
At the top of the cabinet, coil up the surplus fiber optic cable and
attach it to the wall of the cable tray.
Install a lightwave transceiver on cable connector at slot 2A02.
NOTE:
Attenuators may be required for single mode fiber using a
300A Lightwave Transceiver
Connect 1 end of the fiber optic cable to the lightwave transceiver,
just installed, at slot 2A02.
Carefully attach the fiber optic cable (with cable ties) to the wall of
the cable tray at the built-in cable tie positions.
