High Reliability

High Reliability
Required Hardware
The equipment in
a claim for missing equipment, as part of the Streamlined Implementation
process, call 1-800-772-5409, or the number provided by your Avaya
representative.
Table 5-10. Required Hardware
Equipment
J58890A
(PEC 6300-05X)
J58890AF
106647985
103557294
or
103281788
J58890TO-1 L1
407439975
106455348
or
106455363
1. Use 2 for a high reliability system with 2 port networks; 6 with 3 port networks. Either 1
or 4 Expansion Interfaces (EIs) ship loose with the EPN equipment. The factory has
installed either 1 or 2 EIs in the new PPN.
2. Required port network interfaces with the optional packet bus.
3. Use 2 or 6 if the PPN and EPN(s) are remotely located. The fiber that previously
connected an upgraded G2 universal module (not a traditional module) to the G2 TMS
has the correct transceiver connectors and, therefore, can be reused.
4. One pair for each fiber connection. For each connection, install one 9823-type lightwave
transceiver in an EPN and 1 in the PPN. A 9823-type transceiver can be reused from
each upgraded G2 universal module. Additional transceivers also ship loose with the
EPN equipment.
Required Tools
The following tools and items may be required during the upgrade:
High-intensity flashlight or AC drop light
3/8-inch flat-blade screwdriver with a 10-inch shank (minimum)
5/16-inch and 1/4-inch sockets with a ratchet and 10-inch extension
Long-nose pliers to disconnect ground straps and straighten backplane
pins
555-233-115
Table 5-10 must be on-site before the upgrade begins. To place
Description
Processor Port Network
Expansion Control Carrier
TN775B Maintenance
TN776 Expansion Interface
TN570 Expansion Interface
Removable Media
20-Foot Multi-mode Fiber Optic Cable
9823-A Lightwave Transceiver
9823-B Lightwave Transceiver
Quantity
1
1
1
1
2 or 6
1,2
2 or 6
4
3
1 or 3
4
2 or 6
5
2 or 6
Issue 7 November 2003
5-39
