Add Pooled Modem

Add Pooled Modem
Modem pooling supports two types of conversion resources: integrated and
combined.
An integrated conversion requires a Pooled Modem circuit pack for each 2
conversion resources provided.
A combined conversion requires a port of a TN745B or TN2136 Digital Line circuit
pack and a port of either an 8-port TN742, TN769, a 16-port TN746B, or a 24-port
TN793/B, TN2793/B Analog Line circuit pack for each conversion resource
provided.
The pooled modem requires a WP90110 L7 power supply. Although integrated
conversion can use either the L5 or L7, the combined only works with an L7.
!
CAUTION:
The L5 and L7 power supplies look identical. Check the label to be sure you
have the L7 before installing.
Determine the port assignment of the circuit packs to be added (if required).
3. Install the appropriate circuit packs in assigned carrier slot (if required).
4. For Paradyne 3800 series modems:
a. Type AT&F&D2&S4\D3S2=128x7V2S7=60S85=1 and press
b. Type ATY0S10=100S78=2M0E0\N1&W and press
5. For other types of modems, refer to the vendor's documentation.
Settings for Modem Connected to Data Module
1. Type add data-module next and press
2. Type pdm in the Type field.
3. Type x in the Port field.
4. Type dte in the Connected to field and press
5. Type add station next and press
6. Type 2500 in the Type field.
7. Type x in the Port field.
8. Type n in the Tests field and press
9. Type add modem-pool next and press
10. Type combined in the Group Type field.
11. Type 5 in the Hold Time (min) field.
12. Type two-way in the Direction field.
13. Type 9600 in the Speed field.
555-233-115
.
Enter
.
Enter
.
Enter
.
Enter
.
Enter
Issue 7 November 2003
.
Enter
.
Enter
7-29
