Remove Module Control Carrier(s)

Required Tools
The following tools and items may be required during the upgrade:
High-intensity flashlight or AC drop light
3/8-inch flat-blade screwdriver with a 10-inch shank (minimum)
5/16-inch and 1/4-inch sockets with a ratchet and 10-inch extension
Long-nose pliers to disconnect grounding straps and straighten backplane
pins
Static-proof or original circuit pack packaging for transporting circuit packs
Labels for identifying the port circuit packs and cables attached to the rear
of cabinets
Twelve #12 and #10 self-tapping screws
Four spare carrier grounding straps
Wrist ground strap
Repair kit for backplane pins (KS-22876 L2 or equivalent)

Follow Routine Preventive Maintenance

During the upgrade, follow routine preventive maintenance procedures on the
system to be upgraded. For information about the procedures and necessary
equipment, refer to the "Preventive Maintenance" section in Maintenance for
Avaya DEFINITY Server R.

Label Cables

To make reconnecting the cables simpler and more reliable, label both ends of the
connector cables associated with the carrier to be removed.
Remove Module Control Carrier(s)

Check Link Status

1. Type display communication-interface links and press
all enabled links.
2. Type status link number and press
3. Write down which links are in service.

Power Down G2 System

At the power distribution unit, set the main circuit breaker to OFF.
555-233-115
Enter
. Repeat this step for all links.
Enter
Issue 7 November 2003
. Write down
5-69
