MONITORING MENU
4.1.4

I/O

Table 17: I/O signal monitoring
Index Monitoring value
V2.4.1 Slot A DIN 1, 2, 3
V2.4.2 Slot A DIN 4, 5, 6
V2.4.3 Slot B RO 1, 2, 3
V2.4.4 Analogue input 1
V2.4.5 Analogue input 2
V2.4.6 Analogue input 3
V2.4.7 Analogue input 4
V2.4.8 Analogue input 5
V2.4.9 Analogue input 6
V2.4.10 Slot A AO1
4.1.5

TEMPERATURE INPUTS

NOTE!
This parameter group is visible when you have an option board for temperature
measurement (OPT-BH).
Table 18: Monitoring the temperature inputs
Index Monitoring value
Temperature
V2.5.1
input 1
Temperature
V2.5.2
input 2
Temperature
V2.5.3
input 3
Temperature
V2.5.4
input 4
Temperature
V2.5.5
input 5
Temperature
V2.5.6
input 6
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
Unit Scale ID
1 15
1 16
1 17
% 0.01 59
% 0.01 60
% 0.01 61
% 0.01 62
% 0.01 75
% 0.01 76
% 0.01 81
Unit Scale ID
°C 0.1 50
°C 0.1 51
°C 0.1 52
°C 0.1 69
°C 0.1 70
°C 0.1 71
Description
Slot A.1 as default.
Slot A.2 as default.
Slot D.1 as default.
Slot D.2 as default.
Slot E.1 as default.
Slot E.2 as default.
Description
VACON · 119
