Set the signal range of the analogue input
17
Set a value for P3.13.1.8 Error Inversion
18
Set a value for P3.13.2.6 Setpoint Source Selection
19
If you select an analogue input signal, step 20 shows first, and then step 22 shows. With
other selections, the wizard goes to step 21.
If you set Keypad Setpoint 1 or Keypad Setpoint 2 as the value, the wizard goes directly to step
22.
Set the signal range of the analogue input
20
Set a value for P3.13.2.1 (Keypad Setpoint 1) and
21
P3.13.2.2 (Keypad Setpoint 2)
Use the sleep function
22
If you give the value Yes in step 22, you see the next 3 steps. If you give the value No, the
wizard goes to step 26.
2
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
0 = 0-10V / 0-20mA
1 = 2-10V / 4-20mA
0 = Normal
1 = Inverted
See table Setpoints in Chapter Table 75 Set-
point settings
0 = 0-10V / 0-20mA
1 = 2-10V / 4-20mA
Specified by the range set in step 19
0 = No
1 = Yes
WIZARDS
