VACON · 206
The unit of the monitoring value is celsius degrees or fahrenheit degrees, depending on the
'C/F Selection' parameter value.
V2.5.4 TEMPERATURE INPUT 4 (ID 69)
This monitoring value shows the measured value of the temperature.
The unit of the monitoring value is celsius degrees or fahrenheit degrees, depending on the
'C/F Selection' parameter value.
V2.5.5 TEMPERATURE INPUT 5 (ID 70)
This monitoring value shows the measured value of the temperature.
The unit of the monitoring value is celsius degrees or fahrenheit degrees, depending on the
'C/F Selection' parameter value.
V2.5.6 TEMPERATURE INPUT 6 (ID 71)
This monitoring value shows the measured value of the temperature.
The unit of the monitoring value is celsius degrees or fahrenheit degrees, depending on the
'C/F Selection' parameter value.
9.4

EXTRAS AND ADVANCED

V2.6.1 DRIVE STATUS WORD (ID 43)
This monitoring value shows the bit-coded status of drive.
V2.6.2 READY STATUS (ID 78)
This monitoring value shows the bit-coded data about the Ready criteria of the drive.
This data is useful for monitoring when the drive is not in the Ready state.
NOTE!
The values are visible as checkboxes on the graphical display. If a box is selected,
the value is active.
V2.6.3 APPLICATION STATUS WORD 1 (ID 89)
This monitoring value shows the bit-coded statuses of the application.
NOTE!
The values are visible as checkboxes on the graphical display. If a box is selected,
the value is active.
V2.6.4 APPLICATION STATUS WORD 2 (ID 90)
This monitoring value shows the bit-coded statuses of the application.
9
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
MONITORING VALUE DESCRIPTIONS
