Vacon 100 flow Applications Manual page 271

PARAMETER DESCRIPTIONS
Fig. 61: AI1 signal inversion, selection 0
A. Frequency reference
B. Max freq reference
Selection
Selection name
number
1
Fig. 62: AI1 signal inversion, selection 1
A. Frequency reference
B. Max freq reference
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
A
[Hz]
B
C
0%
50%
0 mA 10 mA
Signal inversion. The value 0% of the analogue input signal
agrees to the Maximum Frequency Reference. The value
Inverted
100% of the analogue input signal agrees to the Minimum
Frequency Reference.
A
[Hz]
B
C
0% 50%
0 mA 10 mA
100%
20 mA
C. Min freq reference
D. Analogue input signal
Description
100%
20 mA
C. Min freq reference
D. Analogue input signal
VACON · 271
D [%]
D
[%]
10
