First Startup - Vacon 100 flow Applications Manual

QUICK STARTUP GUIDE
Fig. 2: The graphical display
A. The first status field: STOP/RUN
B. The rotation direction of the motor
C. The second status field: READY/NOT
READY/FAULT
D. The alarm field: ALARM/-
E. The control place field: PC/IO/KEYPAD/
FIELDBUS
Fig. 3: The text display. If the text is too long to show, the text scrolls automatically on the display.
A. The indicators of status
B. The indicators of alarm and fault
C. The name of the group or item of the
current location
1.3

FIRST STARTUP

After you do power-up of the drive, the Startup wizard starts.
The Startup wizard tells you to give necessary data for the drive to control your procedure.
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
A B C D
READY
STOP
Main Menu
ID:
Quick Setup
( 17 )
Monitor
( 5 )
Parameters
( 12 )
F. The location field: the ID number of the
G. An activated group or item
H. The number of items in the group in
A
F
D. The current location in the menu
E. The indicators of the control place
F. The indicators of the rotation direction
E
I/O
F
M1 G
H
parameter and the current location in
the menu
question
B
C
D
E
VACON · 13
1
