WIZARDS
Set the signal range of the analogue input
17
Set a value for P3.13.1.8 Error Inversion
18
Set a value for P3.13.2.6 Setpoint Source Selection
19
If you select an analogue input signal, step 20 shows first, and then step 22 shows. With
other selections, the wizard goes to step 21.
If you set Keypad Setpoint 1 or Keypad Setpoint 2 as the value, the wizard goes directly to step
22.
Set the signal range of the analogue input
20
Set a value for P3.13.2.1 (Keypad Setpoint 1) and
21
P3.13.2.2 (Keypad Setpoint 2)
Use the sleep function
22
If you give the value Yes in step 22, you see the next 3 steps. If you give the value No, the
wizard goes to step 26.
23 Set a value for P3.13.5.1 SP1 Sleep Frequency Limit
24 Set a value for P3.13.5.2 SP1 Sleep Delay
Set a value for P3.13.5.3 SP1 Wake Up Level
25
26 Set a value for P3.15.2 Number of pumps
Set a value for P3.15.5 Pump Interlocking
27
Set a value for P3.15.6 Autochange
28
If you set the value Enabled (Interval or Weekdays) to parameter Autochange, steps 29-34
show. If you set the value Disabled to parameter Autochange, the wizard goes directly to step
35.
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
0 = 0-10V / 0-20mA
1 = 2-10V / 4-20mA
0 = Normal
1 = Inverted
See table Setpoints in Table 75 Setpoint set-
tings
0 = 0-10V / 0-20mA
1 = 2-10V / 4-20mA
Specified by the range set in step 19
0 = No
1 = Yes
Range: 0.00-320.00 Hz
Range: 0-3000 s
The range is specified by the set process
unit.
Range: 1-8
0 = Not used
1 = Enabled
0 = Disabled
1 = Enabled (Interval)
2 = Enabled (Weekdays)
