WIZARDS
Set the signal range of the analogue input
17
Set a value for P3.13.1.8 Error Inversion
18
Set a value for P3.13.2.6 Setpoint Source Selection
19
If you select an analogue input signal, step 21 shows. With other selections, the wizard goes
to step 23.
If you set Keypad Setpoint 1 or Keypad Setpoint 2 as the value, the wizard goes directly to step
22.
Set the signal range of the analogue input
20
Set a value for P3.13.2.1 (Keypad Setpoint 1) and
21
P3.13.2.2 (Keypad Setpoint 2)
Use the sleep function
22
If you give the value Yes for the question 22, you see the next 3 questions. If you give the value
No, the wizard is completed.
23 Set a value for P3.13.5.1 SP1 Sleep Frequency Limit
24 Set a value for P3.13.5.2 SP1 Sleep Delay
Set a value for P3.13.5.3 SP1 Wake Up Level
25
The PID control application wizard is completed.
2.4

MULTI-PUMP (SINGLE DRIVE) APPLICATION WIZARD

The application wizard helps you to set the basic parameters that are related to the
application.
To start the Multi-pump (single drive) application wizard, set the value Multi-pump (Single
drive) to parameter P1.2 Application (ID 212) in the keypad.
NOTE!
If you start the application wizard from the Startup wizard, the wizard goes directly
to step 11.
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
0 = 0-10V / 0-20mA
1 = 2-10V / 4-20mA
0 = Normal
1 = Inverted
See table Setpoints in Table 76 Feedback set-
tings
0 = 0-10V / 0-20mA
1 = 2-10V / 4-20mA
Specified by the range set in step 20
0 = No
1 = Yes
Range: 0.00-320.00 Hz
Range: 0-3000 s
The range is specified by the set process
unit.
