Vacon 100 flow Applications Manual page 85

WIZARDS
Set a value for P3.1.2.2 Motor Type (so that it agrees
with the nameplate of the motor)
1
Set a value for P3.1.1.1 Motor Nominal Voltage (so
2
that it agrees with the nameplate of the motor)
Set a value for P3.1.1.2 Motor Nominal Frequency
3
(so that it agrees with the nameplate of the motor)
Set a value for P3.1.1.3 Motor Nominal Speed (so
4
that it agrees with the nameplate of the motor)
Set a value for P3.1.1.4 Motor Nominal Current (so
5
that it agrees with the nameplate of the motor)
Step 6 shows only, if you selected Induction Motor in step 1.
6 Set a value for P3.1.1.5 Motor Cos Phi
Set a value for P3.3.1.1 Minimum Frequency Refer-
7
ence
Set value for P3.3.1.2 Maximum Frequency Refer-
8
ence
9 Set a value for P3.4.1.2 Acceleration Time 1
10 Set value for P3.4.1.3 Deceleration Time 1
Make a selection of a control place (where you give
the start and stop commands and the frequency
11
reference)
12 Set a value for P3.13.1.4 Process Unit Selection
If your selection is other than %, you see the next 3 steps. If your selection is %, the wizard
goes directly to step 16.
Set a value for P3.13.1.5 Process Unit Min
13
Set a value for P3.13.1.6 Process Unit Max
14
15 Set a value for P3.13.1.7 Process Unit Decimals
Set a value for P3.13.3.3 Feedback 1 Source Selec-
16
tion
If you make a selection of an analogue input signal, you see step 17. With other selections,
the wizard goes to step 18.
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
PM motor
Induction motor
Reluctance motor
Range: Varies
Range: 8.00-320.00 Hz
Range: 24-19200 rpm
Range: Varies
Range: 0.30-1.00
Range: 0.00-P3.3.1.2 Hz
Range: P3.3.1.1-320.00 Hz
Range: 0.1-3000.0 s
Range: 0.1-3000.0 s
I/O Terminal
Fieldbus
Keypad
More than 1 selection
The range is specified by the selection in step
12.
The range is specified by the selection in step
12.
Range: 0-4
See the table Feedback settings in Chapter
Table 75 Setpoint settings
