Vacon 100 flow Applications Manual page 275

PARAMETER DESCRIPTIONS
Table 121: The output signals through RO1
Selection
Selection name
number
Block Out.7
42
Block Out.8
43
Block Out.9
44
Block Out.10
45
46 Jockey pump control
47 Priming pump control
48 Auto-cleaning active
49 Multi-pump K1 control
50 Multi-pump K2 control
51 Multi-pump K3 control
52 Multi-pump K4 control
53 Multi-pump K5 control
54 Multi-pump K6 control
55 Multi-pump K7 control
56 Multi-pump K8 control
69 Selected parameter set
72 AHF Capacitor Disconnection
AHF Capacitor Disconnection
73
Inverted
74 Run indication
P3.5.3.2.2 RO1 ON DELAY (ID 11002)
Use this parameter to set the ON delay for the relay output.
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
Description
The output of the programmable Block 7.See parameter
menu M3.19 Block Programming.
The output of the programmable Block 8. See parameter
menu M3.19 Block Programming.
The output of the programmable Block 9. See parameter
menu M3.19 Block Programming.
The output of the programmable Block 10. See parameter
menu M3.19 Block Programming.
The control signal for the external jockey pump.
The control signal for the external priming pump.
The Pump auto-cleaning function is activated.
The contactor control for the Multi-pump function.
The contactor control for the Multi-pump function.
The contactor control for the Multi-pump function.
The contactor control for the Multi-pump function.
The contactor control for the Multi-pump function.
The contactor control for the Multi-pump function.
The contactor control for the Multi-pump function.
The contactor control for the Multi-pump function.
Shows the active parameter set:
OPEN = Parameter set 1 active
CLOSED = Parameter set 2 active
