Vacon 100 flow Applications Manual page 24

VACON · 24
** = For the DIP switch configurations in VACON
manual.
Fig. 7: The DIP switch
A. Digital inputs
B. Float
Table 5: M1.1 Wizards
Index Parameter
1.1.1 Startup Wizard
1.1.2 Fire Mode Wizard
1
®
C. Connected to GND (default)
Min Max Unit
0 1
0 1
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
100 X, see the VACON
®
A
B
C
Default ID
0 = Do not activate
1 = Activate
0 1170
The selection Activate
starts the Startup wiz-
ard (see 1.3 First
startup).
The selection Activate
starts the Fire mode
0 1672
wizard (see 2.6 Fire
mode wizard).
QUICK STARTUP GUIDE
100 X Installation
Description
