VACON · 98
cannot edit. The other values on the page are Multimonitoring values. You can make a
selection of the values that show up here (see instructions in 4.1.1 Multimonitor).
CHANGING THE ROTATION DIRECTION
You can change the rotation direction of the motor quickly with the FUNCT button.
NOTE!
The command Change direction is available in the menu only if the current control
place is Local.
1 Anywhere in the menu structure, push the FUNCT
button.
2 To make a selection of the Change direction, push
the arrow buttons Up and Down. Push the OK
button.
3 Make a selection of a new rotation direction. The
current rotation direction blinks. Push the OK
button.
3
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
USER INTERFACES
READY
STOP
Main Menu
ID: M1
Monitor
( 7 )
Parameters
( 15 )
Diagnostics
( 6 )
RUN READY
Choose action
ID:1805
Change direction
Control page
Local/Remote
READY
RUN
Choose action
ID:1805
Reverse
Forward
I/O
Keypad
Keypad
